Fig. 3-13 RSTP Port Configuration
Parameter description
Protocol Enabled:
Just tick the check box () beside the port x to enable RSTP protocol, then press
the <Apply> button to apply.
Edge:
Just tick the check box () beside the port x to enable edge function.
Path Cost:
Path cost is the cost of transmitting a frame on to a LAN through that port. It is
assigned according to the speed of the bridge. The slower the media, the higher
the cost, user can select auto or set the rage from 1 to 200000000.
