Microsoft surface hub User Manual

© Microsoft 2015 Page 13
Icon
Location
Description
Bottom right
I’m done: Ends the session. You’ll be prompted to save files and
session content.
Bottom right
Notifications: Shows notifications that have come in—like the
Action center on your PC running Windows 10—and shows
upcoming meetings.
Bottom right
More: Displays additional icons:
Do not disturb
Volume
Restart
Bottom right
Email: Select at any time during a meeting to send all the
meeting notes to that point to any recipient. See Save your
data, below.
Start screen
At any time, you can go to the Start screen to access the whiteboard, start a call, open apps, and more.
Here's how:

Microsoft surface hub Specifications

General

Touch	Yes, multi-touch
Operating System	Windows 10 Team
Display Size	55" or 84"
Processor	Intel Core i5 or i7
RAM	8 GB
Storage	128 GB SSD
Microphone	Dual microphone array
Speakers	Stereo speakers
Connectivity	Wi-Fi, Bluetooth
Ports	HDMI, USB, Ethernet, DisplayPort
