Additional connections icons
Connector, location
Icon
Description
USB type A, side I/O
None
Provides one USB 3.0 connection for USB devices. Wake-on USB
capable.
USB type A, bottom I/O
with blue insulator
Provides USB 3.0 connection
3.5mm, bottom I/O
Provides analog audio out
DisplayPort, bottom I/O
Provides mirrored video out function to another display
IEC/EN60320-C13
receptacle with hard
switch, bottom I/O
None
Provides AC input and compliance with EU power requirements
RJ45, bottom I/O
Connects to Ethernet
RJ11, bottom I/O
Connects to room control systems
Warning icons
Connector, location
Icon
Description
Attention: Caution
Identifies important safety and health messages
Warning: Hazardous
voltage
Dangerous: Do not touch
Read instructions
Read instruction manual for safety and health information
Do not open
No user-serviceable parts inside

Microsoft surface hub Specifications

General

Touch	Yes, multi-touch
Operating System	Windows 10 Team
Display Size	55" or 84"
Processor	Intel Core i5 or i7
RAM	8 GB
Storage	128 GB SSD
Microphone	Dual microphone array
Speakers	Stereo speakers
Connectivity	Wi-Fi, Bluetooth
Ports	HDMI, USB, Ethernet, DisplayPort
