Microtek ArtixScan DI 2125c User Manual

14 ArtixScan DI 2125c User's Manual
Step 3: Connecting the Scanner
To the Power Adapter
1. Connect the power adapter to the back of the scanner.
2. Plug the other end of the power adapter into a wall outlet or other power
source.
To the Hi-Speed USB Cable
3. Connect one end of the Hi-Speed USB cable to your computer.
4. Connect the other end of the Hi-Speed USB cable to the scanner’s USB port.
5. Open top cover (Document Feed Tray) to
turn on the scanner.
Once the scanner is detected by your
system, the LED (green) will brighten, and
the scanner is ready to scan.
Document Feed Tray

Microtek ArtixScan DI 2125c Specifications

Scanning Specifications

optical resolution	600 x 600 dpi
scanning speed (simplex, line art)	20 ppm at 200 dpi
scanning speed (simplex, grayscale)	20 ppm at 200 dpi
scanning speed (simplex, color)	15 ppm at 200 dpi
scanning speed (duplex, line art)	40 ipm at 200 dpi
scanning speed (duplex, grayscale)	40 ipm at 200 dpi
scanning speed (duplex, color)	30 ipm at 200 dpi
scanning area	8.5" x 65" (216 mm x 1651 mm)

Paper Handling

feeder capacity	up to 20 sheets of 20 lb. paper or 1 piece of card
paper weight	10.7 to 32 lbs. (40-120 g/m²)
paper size minimum	3.15" x 2.1" (80 mm x 52 mm)
paper size maximum	8.5" x 65" (216 mm x 1651 mm)
card thickness	up to 0.078" (2 mm)

Roller Life

separation roller assembly life	20, 000 scans
feed roller assembly life	30, 000 scans

Power

input voltage	AC100V-240V, 50-60 Hz, 0.5A max.
output voltage	DC 12V, 1.5A
power consumption	15 W max.

Operating Environment

operating temperature	50° to 95°F (10° to 35°C)
relative humidity	10% to 80%

Weight and Dimensions

dimensions	11.29" x 4.33" x 2.71" (287 mm x 110 mm x 69 mm)
weight	2.64 lbs. (1.2 kg)
