Microtek ArtixScan DI 2125c User Manual

ArtixScan DI 2125c User's Manual 35
Care and Cleaning
To ensure optimal performance from the ArtixScan DI 2125c, it is important to
clean several critical parts of the scanner on a regular basis.
Cleaning the Scanner Glass Surfaces
1. To open the scanner cover, hold the two sides of the scanner cover and pull
them up firmly.
2. When the scanner cover is opened, you can find two scanner glass surfaces
locating at the bottom of the scanner and the inner side of the scanner cover.
Use a soft, non-abrasive and lint-free cloth to gently wipe the glass surface
areas.
Scanner cover
Note: Do not use any detergents, synthetic cleaning solutions, cleaning naphtha,
or other solvents to clean the glass surface directly. To remove stains, use cotton
swabs moistened with rubbing alcohol.
The bottom of the scanner
The inner side of the
scanner cover

Microtek ArtixScan DI 2125c Specifications

Scanning Specifications

optical resolution	600 x 600 dpi
scanning speed (simplex, line art)	20 ppm at 200 dpi
scanning speed (simplex, grayscale)	20 ppm at 200 dpi
scanning speed (simplex, color)	15 ppm at 200 dpi
scanning speed (duplex, line art)	40 ipm at 200 dpi
scanning speed (duplex, grayscale)	40 ipm at 200 dpi
scanning speed (duplex, color)	30 ipm at 200 dpi
scanning area	8.5" x 65" (216 mm x 1651 mm)

Paper Handling

feeder capacity	up to 20 sheets of 20 lb. paper or 1 piece of card
paper weight	10.7 to 32 lbs. (40-120 g/m²)
paper size minimum	3.15" x 2.1" (80 mm x 52 mm)
paper size maximum	8.5" x 65" (216 mm x 1651 mm)
card thickness	up to 0.078" (2 mm)

Roller Life

separation roller assembly life	20, 000 scans
feed roller assembly life	30, 000 scans

Power

input voltage	AC100V-240V, 50-60 Hz, 0.5A max.
output voltage	DC 12V, 1.5A
power consumption	15 W max.

Operating Environment

operating temperature	50° to 95°F (10° to 35°C)
relative humidity	10% to 80%

Weight and Dimensions

dimensions	11.29" x 4.33" x 2.71" (287 mm x 110 mm x 69 mm)
weight	2.64 lbs. (1.2 kg)
