ArtixScan DI 2125c User's Manual 39
Replacing the Feed Roller Assembly
1. Open the scanner cover. Locate the Feed Roller Assembly at the bottom of
the scanner.
Feed Roller Assembly
2. Loosen the screws on the roller cover with a screwdriver. Then hold the roller
cover and pull it out carefully.
Scanner cover
Roller cover

Microtek ArtixScan DI 2125c Specifications

Scanning Specifications

optical resolution	600 x 600 dpi
scanning speed (simplex, line art)	20 ppm at 200 dpi
scanning speed (simplex, grayscale)	20 ppm at 200 dpi
scanning speed (simplex, color)	15 ppm at 200 dpi
scanning speed (duplex, line art)	40 ipm at 200 dpi
scanning speed (duplex, grayscale)	40 ipm at 200 dpi
scanning speed (duplex, color)	30 ipm at 200 dpi
scanning area	8.5" x 65" (216 mm x 1651 mm)

Paper Handling

feeder capacity	up to 20 sheets of 20 lb. paper or 1 piece of card
paper weight	10.7 to 32 lbs. (40-120 g/m²)
paper size minimum	3.15" x 2.1" (80 mm x 52 mm)
paper size maximum	8.5" x 65" (216 mm x 1651 mm)
card thickness	up to 0.078" (2 mm)

Roller Life

separation roller assembly life	20, 000 scans
feed roller assembly life	30, 000 scans

Power

input voltage	AC100V-240V, 50-60 Hz, 0.5A max.
output voltage	DC 12V, 1.5A
power consumption	15 W max.

Operating Environment

operating temperature	50° to 95°F (10° to 35°C)
relative humidity	10% to 80%

Weight and Dimensions

dimensions	11.29" x 4.33" x 2.71" (287 mm x 110 mm x 69 mm)
weight	2.64 lbs. (1.2 kg)
