ArtixScan DI 2125c User's Manual 33

Customizing the Function Button

The ArtixScan DI 2125c is equipped with one programmable function button (F1)

that can be customized to automate a number of predefined operations, such as

scanning to a file, sending an image to your printer, scanning for OCR, etc.

Customizing is done through the “Save Settings to Function Button” command,

as explained below.

1. Launch ScanWizard DI (either as a stand-alone by clicking the program icon,

or by using the “File-Import” or “Scan” command from an application

program).

2. Follow the procedures (steps 3 through 7) for the “Scan a Stack of

Documents” section to specify your scanning requirements in the ScanWizard

DI panel.

3. When you finish specifying the

scanning settings, choose the

“Save Settings to Function Button”

command from the File menu. The

dialog box appears.

F1 Programmable Function button

Questions and Answers:

Need help?

Do you have a question about the Microtek ArtixScan DI 2125c and is the answer not in the manual?

Microtek ArtixScan DI 2125c Specifications

Scanning Specifications

optical resolution	600 x 600 dpi
scanning speed (simplex, line art)	20 ppm at 200 dpi
scanning speed (simplex, grayscale)	20 ppm at 200 dpi
scanning speed (simplex, color)	15 ppm at 200 dpi
scanning speed (duplex, line art)	40 ipm at 200 dpi
scanning speed (duplex, grayscale)	40 ipm at 200 dpi
scanning speed (duplex, color)	30 ipm at 200 dpi
scanning area	8.5" x 65" (216 mm x 1651 mm)

Paper Handling

feeder capacity	up to 20 sheets of 20 lb. paper or 1 piece of card
paper weight	10.7 to 32 lbs. (40-120 g/m²)
paper size minimum	3.15" x 2.1" (80 mm x 52 mm)
paper size maximum	8.5" x 65" (216 mm x 1651 mm)
card thickness	up to 0.078" (2 mm)

Roller Life
