4. OPERATION
WARNING!
This equipment is intended for use by suitably trained and competent persons.
This product can cause hazards if it is not used in accordance with these instructions.
Read them carefully and follow them in all respects. Double check connections to the unit
before use.
DO NOT USE THIS EQUIPMENT IF IT IS DAMAGED.
4.1 The Rear Panel
Figure 4-1 The 6375 Series Rear Panel
4.1.1 Voltage Selector
The instrument can be operated from an AC power source of either 115V or 230V. Before
applying AC power to the IEC socket, ensure that the voltage selector switch is set to the
voltage of the local AC power supply.
4.1.2 IEC Socket and Fuse Holder
Please read section 1.2 before connecting the IEC socket to the AC power source.
