1-6 GENERAL MDS 05-2415A01, Rev. A
General Continued
Model 4350 and 4355 Packaged Radios
Voltage: 120/220 Vac with 5 ampere-hour
Battery Back-up (Standard)
12, 24, 48, & 125 Vdc (Optional)
DC Supply: Positive, Negative;
Floating Ground with 24, 48, & 125 Vdc
TX Power Consumption: 50 watts maximum at rated output
RX Power Consumption: 5 watts maximum
Transient Protection: 2500 Volt Isolation on Voice Frequency (VF)
Inputs and Outputs, Power Supply & Keying
Dimensions:
Model 4310 Transceiver 2.0" x 5.62" x 7.25"
50 x 143 x 184 mm
(Not including mounting hardware or
connector housings)
Model 4350 Packaged Radio 9.5" x 17.5" x 19.5"
241 x 445 x 495 mm
(Not including mounting hardware or
connector housings)
Model 4355 Packaged Radio 6.5" x 11.85" x 13.75"
165 x 301 x 350 mm
(Not including mounting hardware or
connector housings)
Weight:
Model 4310 Transceiver Maximum 3.5 Lbs./1.6 kg
w/all options installed
Model 4350 Packaged Radio Maximum 33 Lbs/15.0 kg
w/all options installed
Model 4355 Packaged Radio Maximum 21 Lbs/9.53 kg
w/all options installed
Transmitter
Frequency Range: 350–512 MHz (Nominal)
Operating Bands— 350–370 MHz, 370–390 MHz, 390–410 MHz,
any one of eight: 406–430 MHz, 430–450 MHz, 450–470 MHz,
470–490 MHz, and 490–512 MHz
Frequency Programming: Programmable in 6.25 kHz increments to any
channel pair in radio operating sub-band.
TX/RX Spacing: 0 (Simplex), 5 MHz, 10 MHz standard; others
are possible, consult with factory.
