1-10 GENERAL MDS 05-2415A01, Rev. A
Environmental
Temperature Range: Full Performance: –30°C to + 60°C
Operational Performance: –40°C to +70°C
Humidity: 95% at + 40°C Non-Condensing
Case: Model 4310–Die-Cast Aluminum
Model 4350–Die-cast aluminum inside a
NEMA 4 Outdoor Housing, w/Padlockable
Latches
Model 4355–Die-cast aluminum inside a
NEMA 4 Outdoor Housing, w/Padlockable
Latches
AGENCY APPROVALS
FCC: Part 15.247 FCC approved
Underwriters Laboratories (UL)*: UL Approval for Class 1, Div. 2; Groups
A, B, C and D; hazardous locations
Factory Mutual (FM)*: FM Approval for Class 1, Div. 2; Groups
A, B, C and D; hazardous locations
* These certifications available on special orders.
FCC INFORMATION (USA)
†
PART 90
Transmitter Model: E5M5LL2013
Channel Capacity: 1
Frequency Tolerance: ±0.00015%
Output Power :
(Continuously Variable) 0.1 to 2 watts 0.1 to 5 watts
Necessary Bandwidth: 12.5 kHz 25 kHz
Emission Designators: F1D: 16K0 16K0
F2D: 16K0 16K0
F3D: 16K0 16K0
†
Contact MDS for information on availability and governmental approvals in other countries.
OPTIONAL EQUIPMENT, ACCESSORIES and CERTIFICATIONS
The MDS 4310 Data Transceiver can be supplied with the following options. For information
on adding options to MDS radios, please contact the MDS Marketing Department.
Special Certifications
Some models of the MDS 4300 Series transceivers are available with either Factory Mutual
(FM) or Underwriter’s Laboratory (UL) Approval for operation in Class I, Groups ABCD,
