MDS 05-2415A01, Rev. A PROGRAMMING AND DIAGNOSTICS 3-11
PROGRAMMING AND TEST COMMANDS
Table 3-2 contains a list of all HHT programming and diagnostics commands.
NOTE
Some command strings in Table 3-2 include an underscore “_”
symbol to denote a
SPACE key press. The underscore is a visual
reminder only, and should not be entered.
Table 3-2. Programming and Test Commands—Part 1 of 3
DIAGNOSTICS CHANNEL
OPEN... OPEN the Diagnostics Channel CLOS... CLOSE the Diagnostics Channel
DISPLAY COMMANDS
HARDWARE STATUS
STAT .... Display status of hardware profile
Displayed below are the functions of each display character and its meaning.
1 Keyed Status ................ U – Unkeyed
K – Keyed
T – Timed Out
2 Diagnostic Mode .......... S – Standard (Mode 1)
A – Advanced (Mode 2)
R – Remote Maint. (Mode 3)
3 Diagnostic Hardware ... A – Installed, LBC Valid
B – Installed, LBC Invalid
C – Uninstalled, LBC Valid
D – Uninstalled, LBC Invalid
4 Diagnostic Module ....... I – Installed
U – Uninstalled5
Base/Remote .............. B – Base (High Side LO)
R – Remote (Low Side LO)
6 IF/LO Arrangement ..... 0 – 45 MHz/Low
7 RSSI Cal. Status.......... Y – Calibrated
N – Uncalibrated
8 RF Power Status.......... Y – Calibrated
N – Uncalibrated
OWNER’S INFORMATION
OWM .... Display Owner’s Message OWN .... Display Owner’s Name
RADIO INFORMATION
HREV ... Transceiver hardware revision level
MD........ Transceiver manufacture date
MO ....... Model number of radio
SER...... Serial number of radio
SREV... Transceiver firmware revision level
OPERATING PARAMETERS
CTS...... Displays CTS delay in ms
FRQ ..... Frequencies currently set in MHz
LBC ...... Display Loopback code (4 digits)
SCD Display Soft Carrier Dekey in ms
PTT ...... Display Push-to-Talk delay in ms
STE ...... Display Squelch Tail Eliminator (STE)
Status— ON or OFF (Normally OFF if VOX
function is used.)
TOT...... Display Time-out Timer length (sec)
DIAGNOSTIC INFORMATION
FPWR .. Forward RF power*
LV ........ PLL VCO lock voltage
RPWR .. Reverse RF power*
RSSI .... Received Signal Strength Indicator*
SV........ Supply voltage to radio*
TEMP... Internal temperature in degrees Celsius*
VR........ Regulator voltage output ≈8 Vdc*
VSWR.. VSWR at ANTENNA connector*
* Information is updated every second
