MDS 05-2415A01, Rev. A PROGRAMMING AND DIAGNOSTICS 3-5
Setting the Operating Parameters
The user can select and set several of the operating parameters of the radio. These parameters
include:
• Transmit Frequency
• Receive Frequency
• Time-out Timer Length
• Enable or Disable Time-out Timer
• Squelch Tail Eliminator Status
• RTS/CTS Delay Interval
• Soft Carrier Dekey Delay Length
• Loopback Code
• Push-To-Talk Delay
Program User Information
The user can program information into the radio that is specific to the individual user. This
information includes:
• Owner’s Name (20 characters total)
• Owner’s Specific Message
(For example—assigned location or date unit placed in service. 27 characters total).
This information is stored in EEPROM, and will remain programmed in the radio until new
information is entered.
USING THE HAND-HELD TERMINAL—Basic Operations
Command Syntax
The proper procedure for using the review commands is the command, followed by an
ENTER
keystroke. For the programming commands, the appropriate command is followed by a
SPACE
keystroke, followed by the information or values, then
ENTER
. See Programming Examples
for further information.
Shift Key
The shift key is used to access the numbers on the keyboard of the HHT. Pressing the
SHIFT
key once locks the keyboard into the upper level character set; the
SHIFT
key has to be
pressed again to return to the main character (alphabet) set. Exception: Pressing the
ENTER
key automatically returns the keyboard to the main character set.
Backspace (BKSP) Key
The Backspace key
BKSP
can be used to edit information or commands as they are being
entered with the keyboard. The backspace key works only when the
SHIFT
key has the
alphabet selected.
