Midea UL-BD386WE-SQ

Service Manual, 2016-12
27 / 47
Main control board
remove the fixed screw from main control
board box
Open the main control board box
coverremove the fixed screw,pull out the
main control boardDisconnect the connector
of main control board
8.8 Bar counter(None)
Disassembly and installation of bar counter
None
Disassembly and installation bar doorseal
None
8.9 Water dispenser(None)
Disassembly and installation of water valve
None
Disassembly and installation of water tank
None
