16
Removal and Replacement
1. Disconnect power supply.
2. Remove shell. (see shell removal and installation)
3. Unfit snap of door lock assembly, and push it out.
4. Pull out all terminals of microswitch fixed on the door lock assembly.
5. Reverse the above procedure to install. And check out all connectors connected well.
Removal and Replacement
1. Remove shell. (see shell removal and installation)
2. Take out absorbing cotton, upper basket and lower basket.
3. Contrarotate nut of air breaker and take out it.
4. Pull out terminal of air breaker, and unfit snaps of air breaker fixing on softener.
1
2
3
4
clamps
