18
4. Remove all screws for fixing hinge assembly to bottom board.
5. Reverse the above procedure to install. And check out all connectors connected well.
Removal and Installation
1. Remove shell. (see shell removal and installation)
2. Take out absorbing cotton.
3. Remove air breaker. (see air breaker removal and replacement)
4. Remove all screws for fixing tank assembly to bottom board.
5. Reverse the above procedure to install. And check out all connectors connected well.
Screws
Screws
