ID Code 01 (Machine Control Board) - continued
Error Code Error Denition Probable Cause Correction
1b
Communication Error to
Motor Control
Message failure.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
Loose wire connection.
Check and secure wire connections at J3 on Power Supply PC Board
and J13 on Motor Control Hub PC Board.
Check and secure wire connections at J16 on Machine Control PC Board
and J14 on Motor Control Hub PC Board.
Power Supply PC Board fuse(s) blown. Test / Replace F3 & F4 fuses on Power Supply PC Board.
1C
Communication Error to
Motor Control
Communication failure.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
1d
Communication Error to
Keypad
Message failure.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
1E
Communication Error to
Keypad
Communication failure.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
1F
Communication Error to
Keypad
Communication failure.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
20
Communication Error to
Keypad
Message failure.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
21
Serial Diagnostics Port Error Communication failure.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
22
Corrupt Memory Last save to memory failed.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
23
Memory Save Error Saving to memory failed.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
24
Memory Recall Error Recalling information from memory failed.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
25
Memory Erase Error Erasing information from memory failed.
Disconnect power cord for at least ve seconds, then plug back in.
Replace Machine Control PC Board.
26
Incorrect Movement
An axis was detected moving when the commanded
motion was to be stopped.
Error goes away by itself.
Disconnect power cord for at least ve seconds, then plug back in.
