Problem Symptom Probable Cause Check Solution
Base function not
operating properly.
No Base Up. Active Sensing Technology
TM
activated. For obstruction under foot section. Remove object from under foot section.
System malfunction. Error code on Machine Control PC Board. Refer to: Error Codes
Malfunctioning Wired Controls. Wired Controls. Refer to: Wired Controls Malfunctioning
Malfunctioning Wireless Controls. Wireless Controls. Refer to: Wireless Controls Malfunctioning
Foot Smart Sensor switches. Check wire connections at J18 on Machine
Control PC Board and at switches.
Secure wire connections.
Refer to: Fuses and Connections
Check Green and White wire connections
at four pin inline connection next to
Motor Control Hub PC Board.
Secure wire connections.
Test switches.
Refer to: Smart Sensor Switches
Replace Switch(es).
Base Up limit switch. Wire connections at J5 on Power Supply
PC Board and at limit switch.
Secure wire connections.
Refer to: Fuses and Connections
Test limit switch.
Refer to: Base Actuator / Limit Switches
Replace limit switch.
Base Up Overtravel limit switch. Wire connections at J5 on Power Supply
PC Board and at limit switch.
Secure wire connections.
Refer to: Fuses and Connections
Test limit switch.
Refer to: Base Actuator / Limit Switches
Replace limit switch.
Troubleshooting Chart - continued
