Preva Installation/Service Manual, 00-02-1577, Revision E01
97
Figure 72
5. Unplug the black and white connector.
Figure 73
6. Remove the two Allen head screws that secure the two ground wires to
the yoke. Take note of the position of each ground wire.
Figure 74
7. Remove the end cap from the side of the tubehead.
Figure 75
8. Remove the small Phillips head screw that holds the cable restraint.
