Appendix A: Test Result DescriptionsDSS-5000 HD
Appendix A: Test Result Descriptions
Battery Test Results
Reserve
Capacity
Conductance
Result
Overall
Result
State Of Health Message Reserve Capacity Message
Good Good
Good
Battery
Battery meets or exceeds required
standards. Test again in 90 days or at next
service opportunity.
The battery has sufcient reserve capacity
to provide power for the electronics
systems in the vehicle.
Good
Good-
Recharge
Good-
Recharge
Battery is good, but low on charge. Fully
charge the battery for optimal performance
and life. Check for causes of low charge.
Good
Charge &
Retest
Charge &
Retest
Battery requires charge to determine
condition.
Good
Replace
Battery
Replace
Battery
Battery fails to meet industry accepted
standards.
Good
Bad Cell-Short
Replace
Bad
Cell-Short
Replace
Battery fails to meet industry accepted
standards.
Warning Good
Replace
Battery
Battery is good for cranking purpose but
shows low reserve capacity. Low reserve
capacity will comprise the battery's ability to
provide system current and hold a charge.
The reserve capacity of the battery is
low. Low reserve capacity of the battery
could impact the ability of the battery to
provide power for the electronics systems
in the vehicle, such as console screen,
entertainment systems, power seats, etc.
Recommend replacing the battery.
Warning
Good-
Recharge
Replace
Battery
Battery is good for cranking purpose but
shows low reserve capacity. Low reserve
capacity will comprise the battery's ability to
provide system current and hold a charge.
Warning
Charge &
Retest
Replace
Battery
Battery is low in charge and shows low
reserve capacity. Low reserve capacity
will comprise the battery's ability to provide
system current and hold a charge.
Warning
Replace
Battery
Replace
Battery
Battery fails to meet industry accepted
standards.
Warning
Bad Cell-Short
Replace
Replace
Battery
Battery fails to meet industry accepted
standards.
No Test Good
Good
Battery
Battery meets or exceeds required
standards. Test again in 90 days or at next
service opportunity.
System conditions have prevented a test of
the battery reserve capacity in this vehicle.
Before attempting any retest, ensure that
all vehicle accessory loads are off, the key
is not in the ignition, and the doors are
closed.
No Test
Good-
Recharge
Good-
Recharge
Battery is good, but low on charge. Fully
charge the battery for optimal performance
and life. Check for causes of low charge.
No Test
Charge &
Retest
Charge &
Retest
Battery requires charge to determine
condition.
No Test
Replace
Battery
Replace
Battery
Battery fails to meet industry accepted
standards.
No Test
Bad Cell-Short
Replace
Bad
Cell-Short
Replace
Battery fails to meet industry accepted
standards.
