Appendix B: Test ParametersDSS-5000 HD
VIN A unique code, including a serial number, used to identify individual motor vehicles, motorcycles,
scooters and mopeds, as dened in ISO 3833.
Vehicle Year Model year that a vehicle was manufactured.
Vehicle Make Vehicle manufacturer
Vehicle Model Vehicle name or number
Vehicle Technology Hybrid, Gasoline, Electric, Start-Stop, Hybrid Start-Stop, Diesel
Mileage Mileage of vehicle being tested
Pack Single or dual battery pack
Alt Remote Sense Vehicle remote option to detect voltage at the alternator rather than the battery pack
Battery Application
Automotive, Marine, Powersports, Group 31 , Commercial 4D/8D, Lawn and Garden
Battery Type
Flooded, AGM (Absorbed Glass Mat), AGM Spiral, Gel, Enhanced Flooded, NorthStar Odyssey Pure Lead
Battery Units
CCA Cold Cranking Amps: Battery current at 0 ºF (–17.8 ºC). 100 to 3000
CA
Cranking Amps:
Battery current at 32°F (0 ºC). 100 to 3000
JIS
Japanese Industrial Standard: Usually printed on battery label. 26A17 to 245H52
DIN(A) Deutsches Institut für Normung 100 to 1000
SAE(A) European labeling of CCA 100 to 3000
IEC(A) International Electrotechnical Commission 100 to 1000
EN(A) Europa-Norm 100 to 1700
EN2(A) Europa-Norm 100 to 1700
Battery Rating Enter the Battery Rating Units value.
RC/Ah Test Reserve Capacity or Amp Hours
Reserve Capacity/
Amp Hours
Enter numeric value for Reserve Capacity or Amp Hour value
Notes Enter specic job notes or RO number
Num of Batteries Enter a numeric value for the number of batteries in the pack being tested.
NOTE: If no Reserve Capacity/Amp Hours value is entered, the analyzer will use the average RC rating for a ooded
Group 31 battery (180 minutes).
