Drainage
Connection to the drainage system
and disposal of waste water must
comply with local and national
regulations.
–
The drainage system is fitted with a
non-return valve which prevents
waste water from flowing back into
the machine via the drain hose.
–
The machine should preferably be
connected to a separate drainage
system onsite.
If separate drainage is not available,
contact your Miele application
specialist for advice.
The on-site connection needs to be
between 2 ft. (0.6 m) and 3 ft 3" (1 m)
high measured from the lower edge
of the machine.
If the connection is deeper than 1 ft.
(0.3 m), lay the drain hose ensure the
hose runs at least 1 ft. (0.3 m) high.
The drainage system must
accommodate a minimum flow rate
of 16 l/min.
–
The flexible drain hose is 4 ft 7
1
/
8
"
(1.4 m) long. The clearance is
7
/
8
"
(22 mm). Do not cut the drain hose.
Hose clamps for installation are
enclosed.
–
A longer drain hose (up to 13 ft [4 m]
long) is available to order from the
Miele Technical Service Department.
–
The drainage system must not
exceed 13 ft [4 m] .
See also the installation diagram
supplied.
Plumbing
74
