Miele PG 8130 U - Adjusting the Upper Basket

Loading the commercial dishwasher
33
Adjusting the upper basket
In order to gain more space for taller
items, the upper basket can be
adjusted on three levels with 2cm (3/4")
between each level.
The upper basket can also be set at an
angle so that water can run off freely
from recesses. Make sure, however,
that the basket can slide smoothly in
and out of the cabinet.
 Pull out the upper basket.
To raise the upper basket:
 Lift the basket up until it clicks into
place.
To lower the upper basket:
 Pull upwards on the levers at either
side of the upper basket.
 Adjust the basket to the desired
height and then push the levers
securely back down into position.
Depending on the setting of the upper
basket, the following plate dimensions
can be accommodated.
Dishwasher with cutlery basket
(see data plate for model number)
Upper
basket
position
Plate  in cm
Upper basket Lower
basket
Normal XXL
Top 20 24 31 (35*)
Middle 22 26 29
Bottom 24 28 27
Dishwasher with cutlery tray
(see data plate for model number)
Upper
basket
position
Plate  in cm
Upper basket Lower
basket
Normal XXL
Top 15 19 31 (35*)
Middle 17 21 29
Bottom 19 23 27
* When tilted, plates of up to 35cm (133/4“)
can be accommodated (see ”Lower
basket“).
