Electrical connection
72
The PG 8130 U / PG 8130i comes
equipped with a 14/3AWG cord for
connection to a standard AC 120V,
60Hz power outlet with a NEMA 5-15P
plug.
If available, the dishwasher may be
connected to a 2N AC 120/208-240V,
60Hz power supply. This will increase
the power to the heating elements and
shorten the time of selected wash
cycle.
120V 208 –
240V
Rated load
(kW)
1.5 3.9–4.2
Fuse rating 15A 30A
To connect the machine to a 2N AC
120/208-240V supply, the standard
power cord must be removed and
replaced by a 10/4AWG cable of the
type: S, SE, SO, SOO, ST, STO or
STOO. A 3-pole, 4-wire grounding plug
and receptacle are recommended
(NEMA Type 14-30P).
The conversion diagram and wiring
diagram are secured to the inner side of
the base cover.
Removing the toe kick
Disconnect the machine from the
electrical supply.
 Remove the fixing screws from the
toe kick and take it off.
Power connection options
