Adding and dispensing chemical agents
49
DOS modules
If required, up to two additional, external DOS modules for liquid
agents can be fitted retrospectively.
External DOS modules are fitted by Miele Service or a suitably
qualified and approved technician. Internal dispensing systems
cannot be retrospectively fitted.
Connecting DOS
modules
DOS modules are supplied with their own installation instructions.
Before fitting the DOS module, compare the connection data
(voltage and frequency) on the data plate with that on the data
plate of your machine. If the data does not match, the modules
could sustain damage. If in any doubt, consult an electrician.
Power supply for DOS3 neutralising agent.
Power supply for DOS4, rinsing agent.
Connections for dispenser hoses.
Connect the module to the electricity supply.
To connect the dispensing hose, release the hose clip on a free
connector and remove the safety cap.
Push the dispensing hose onto the connector and secure it with a
hose clip.
Unused connectors must be blanked off with safety caps to
prevent the leakage of wash fluid.
Dispensing liquids
For adjusting the dispensing concentration, see “Further settings/
Dispensing systems”.
