Technical Information
53
PW 6xx7
MDU fault # Possible cause Notes Indication in EW 235
display
Fault/Information
F4119 Checksum fault -
Operating fault
Internal fault in control data
memory. Checksum for
monitoring memory area for
operating faults in control is
incorrect.
“Data fault. Limited
function. Operating
data defective.”
Fault
F4121 Checksum fault -
Standard programs
Internal fault in control data
memory. Checksum for moni-
toring memory area for standard
programs in control is incorrect.
“Data fault! Call the
service department if
restart does not work.”
Fault
F4122 Checksum fault -
Standard blocks
Internal fault in control data
memory. Checksum for moni-
toring memory area for standard
blocks in control is incorrect.
“Data fault! Call the
service department if
restart does not work.”
Fault
F4123 Backup comparison
fault
After power is switched on, a
welcome greeting is shown.
After a few seconds buzzer
sounds and “Data fault no. 123”
is displayed. Control could not
carry out a complete backup
data comparison between ELP
235 and EW 235 modules.
“Data fault no. 123” Fault
F4124 Drive fault. No drum
rotation.
3 min after activation signal
drum has not started to rotate.
Tachogenerator could be short-
circuited.
“Drive system fault.
Call the service
department if restart
does not work.”
Fault
F4125 Allotted time
exceeded (timeout) in
communication
between control ELP
235 and frequency
converter EFU 235
Data exchange between control
and frequency converter
modules has been interrupted.
Open circuit in connection from
ELP 235 plug N1L_ST11 and
EFU 235 plug N1D_ST3, or F3
motor thermostat has cut out.
Frequency converter relay K1/9
does not switch. Frequency
converter defective.
Tachogenerator signal short
circuit registered during
measuring speed.
Without a wash
program in progress:
No display. During a
wash program: ”M”,
“Drive system fault.
Call the service
department if restart
does not work.”
Fault
F4126 Tachogenerator
connection fault
Tachogenerator connections
open- or short-circuited. Only
one lead between motor and
frequency converter defective.
After program start in washing,
information is displayed and
drum turns slowly for 3 s. After
program start in spin, infor-
mation is displayed and for
entire duration of spin cycle
control repeatedly operates
drive motor for 3 s slowly and
then stops.
Without a wash
program in progress:
No display. During a
wash program: “Drive
system fault. Safety
time active! xx min yy
s”
Fault
F4127 Tachogenerator
connection fault after
safety time
Tachogenerator defective.
Before door is released, safety
time until drum is definitely
stationary must have elapsed.
Every power interruption during
safety time will cause this fault
to be registered again and
safety time to restart from
beginning.
“Drive system fault.
Safety time active! xx
min yy s”
Fault
