Technical Information
13
PW 6xx7
015 Weighing System
2 Function
2.1 General
The weighing system is used for the following applications:
Laundry weighing (up to 40kg) before program start
Laundry weighing at program end to determine residual moisture
percentage
The possible parameter settings in the weighing-program header will have
the following influence:
No
The nominal load will always be displayed in the “Actual
load” display. The weighing system is not used. The “Actual
load” entry field is not accessible.
Manual
An externally measured weight can be entered manually
before program start. The weighing system is not used.
Automatic
(default)
Actual load is provided by the weighing system and cannot
be manually changed. If the weighing system is
defective, then Automatic will not be available (“Manual”
only).
2.2 Display Before and After Program Start
There is no loading option in the program list.
1 Cottons 95°C
2 Colors 60°C
3 Delicates 60°C
Manual
control
Dispensing
off
Settings
The loading option will appear after a program has been selected.
2 Colors 0.0 / 10.0 kg
60°C Main wash
Rinse 1000 rpm
Block + Starch stop Spin stop Start time Reset display
