Technical Information
9
PW 6xx7
B Modification History
When? Who? What?
8/22/2014 Jessica Naples Weighing-system info added
12/21/2011 Jessica Naples PW 6207 and steam info added
12/16/2011 Jessica Naples Conversion for Website
C Technical Data
PW 6107 PW 6137 PW 6167 PW 6207
Heating Electric or steam
Capacity (dry laundry) 23 lbs 29 lbs 35 lbs 44 lbs
Width 32” 32” 36.4” 36.4”
Depth 36” 40” 39.6” 44.9”
Height 49” 49” 55.1” 55.1”
Net weight 714 lbs 750 lbs 1045 lbs 1118 lbs
Max. floor load in operation (force)
3931N (electric);
3970N (steam)
4294N
(electric);
4304N (steam)
5675N (electric);
5469N (steam)
6203N (electric);
6076N (steam)
Total rated load
11kW (electric);
2.3kW (steam)
17kW (electric);
2.3kW (steam)
18kW (electric);
3kW (steam)
18kW (electric);
3kW (steam)
Heater rating 9kW 15kW
15kW (electric);
35kW (steam)
15kW (electric);
32kW (steam)
Drive motor rating (wash cycle) 2200W 2200W 3300W 4300W
Electrical connection, standard 3 AC 220/240 V 60Hz
Fuse rating 3AC 220-240V 60Hz 3 x 25A 3 x 50A 3 x 50A 3 x 50A
Water supply Hot and cold 5 ft. long with ¾” hose thread
Plumbing
Cold: 2 x 1/2" hoses
Hot 70°C: 1 x 1/2" hose
Cold-hard (optional): 1 x 1/2" hose
Inlet valve flow rate KW 1 x 10 L/min, 1 x 16 L/min; WW 1 x 16 L/min; optional KH 2 x 16 L/min
Max. intake rate
Cold: 1 x 10, 1 x 16 L/min
Cold-hard: 2 x 16 L/min
Hot: 1 x 16 L/min
Required water flow pressure Minimum 30 psi, maximum 145 psi
Drain connection 3 in. diameter vented drain valve
Max. drain flow rate 53 gallons/minute
Drum diameter 23.2” 26.7”
Drum depth 14.4” 18.7” 17.3” 21.7”
Drum volume 3.5 cu.ft. 4.6 cu.ft. 5.6 cu.ft. 7.1 cu.ft.
Door opening diameter 14.6”
Max. drum speed 1200 rpm 1100 rpm 1150 rpm 1100 rpm
G-force 0.67
Table C-1: Machine Specifications
PW 6107 PW 6137 PW 6167 PW 6207
Heating type EL
D
EL D EL D EL D
Temperature increase rate (low water level) 2.5°C/
min
10°C/
min
3.4°C/
min
8.3°C/
min
2.8°C/
min
8.5°C/
min
2.7°C/
min
8.6°C/
min
For disinfection programs, add on the corresponding holding times.
Table C-2: Consumption Data Sheet, March 2011
1
Electric
2
Steam
