Technical Information
88
PW 6xx7
10. This spin profile is used, for example, with the Delicates program in the
basic program packet.
Figure 100-10: User-defined spin profile example - Delicates program in the basic
program packet.
Ph1
Phase 1, pre-extraction, time 1 min 0 s, rhythm “No”, speed 300 rpm
Ph2
Phase 2, loosening, time 0 min 30 s, rhythm “Delicate”, speed “Normal”
Ph3
Phase 3, final spin, time 1 min 0 s, rhythm “No”, speed 600 rpm
Ph4
Phase 4, loosening, time 0 min 30 s, rhythm “Delicate”, speed “Normal”
Ph5
Vacant
Ph6
Vacant
Max.
Maximum permitted spin speed selection; see also Table 100-36.
For a PW 6137 model this means a spin profile with 4 spin phases: 1 minute
pre-extraction with 300 rpm, followed by 30-second loosening with 44 rpm
with rhythm 5-second agitation and 10-second pause. Then a final spin for 1
minute with 600 rpm. Finally, loosening for 30 seconds with 44 rpm with
rhythm 5-second agitation and 10-second pause. Spin phases 5 and 6 are
not programmed.
Maximum selectable spin speed for different models:
Model Maximum spin speed
PW 6107 1200 rpm
PW 6137 1100 rpm
PW 6167 1150 rpm
PW 6207 1100 rpm
Table 100-36: Maximum Selectable Spin Speed for Different Models
Note:
The highest programmed speed for a spin profile spin phase in the last
block of a program sets the maximum possible speed for all preceding
blocks that have “Free spin speed selection” = “Yes” programmed. For
example, if in the last spin profile of the last block the laundry is only
loosened with 44 rpm, the maximum programmed speed is then 44 rpm. In
all preceding blocks of this program with “Free spin speed selection” = “Yes”
programmed, no spin will be carried out. The drum rotates with 44 rpm.
