Miele PWM 507 User Manual

Before using for the first time
22
The programmes are activated (framed)
or deactivated (no frame).
 Confirm with the OKsensor.
The display switches back to the pro-
gramme packages.

Programme
packages


Disinfection

Continue

 Select other programme packages or
confirm your selection with the Con-
tinuesensor.
The display will change to the next set-
ting.
Setting up a payment system
If you wish to set up a payment system,
read “Payment system” under “Super-
visor level”.
If you do not wish to set up a payment
system, you can skip this stage.

Payment
system


No payment
system
Programme
control
 Touch the No payment systemsensor.
The display will change to the next set-
ting.
Select pre-wash water

Pre-wash
water
Cold
Hot
 Touch the coldsensor if the washing
machine is only connected to a cold
water supply, or touch hotif the
washing machine is connected to
cold and hot water.
The display will change to the next set-
ting.
Select main wash water

Main wash
water
Cold
Hot
 Touch the coldsensor if the washing
machine is only connected to a cold
water supply, or touch hotif the
washing machine is connected to
cold and hot water.
Further information will appear on the
display.

Miele PWM 507 Specifications

General

Drum capacity	7 kg
Delay start (max)	24 h
Spin-drying class	A
Maximum spin speed	1600 RPM
Noise level (spin)	72 dB
Noise level (wash)	- dB
Delayed start timer	Yes
Number of washing programs	-
Current	16 A
AC input voltage	400 V
AC input frequency	50 Hz
Energy efficiency scale	A to G
Water consumption per cycle	37 L
Energy consumption washing per cycle	- kWh
Door hinge	Right
Water fill	Cold, Hot
Drum volume	64 L
Control type	Rotary
Loading type	Front-load
Product color	White
Door opening angle	167 °
Appliance placement	Freestanding
Package weight	104000 g

Weight and Dimensions

Depth	714 mm
Width	605 mm
Height	850 mm
Weight	100000 g
Door diameter	300 mm
