Installation
63
Wi-Fi/LAN
interface
The washing machine is fitted with a Wi-Fi/LAN interface for the
purpose of data exchange.
The data interface provided at the LAN connection complies with
SELV (Safety Extra Low Voltage) in accordance with IEC 62368-1. The
LAN connection uses an RJ45 connector in accordance with EIA/TIA
568-B.
Connected appliances must also comply with SELV.
Plinth
(APWM037/038/03
9)
The machine can be installed on a plinth (open or box plinth, available
as an optional Miele accessory).
Elevating the washing machine gives a better ergonomic working
position when loading or unloading. It also simplifies the installation
of a waste water connection.
The washing machine must be secured to the plinth
immediately after installation. The plinth must be secured to the
floor.
There is a risk of the washing machine falling off a raised plinth
during a spin cycle if it is not secured.
