Mighty Mule MM571W - Items Included for Primary Gate Opener Installation (MM571 W); Items Included for Secondary Gate Opener Installation (MM572 W)

MM571W / MM572W Installation Instructions xiii
Battery Box, Control Box,
Antenna, Battery
& Battery Harness
Operator
Arm
Gate Bracket
Post Pivot Bracket
Post Brackets (2)
Transformer
Literature kit
with gate
warning signs
Closed Position
Stop Plate
Transmitter
A
F
G
I
E
B
C
H
D
8” Nylon Cable Tie (10)
J
3/8” Washer (9)
5/16” Clipped Washer (1)
K
L
3/8” x 8” Bolt (4)
M
3/8” x 1-1/2” Clevis Pin (2)
2” Mounting Screw (4)
S
R
3/8” Nut (7)
5/16” Lock Nut (1)
U
T
5/16” x 1-1/2” Bolt (1)
Q
W
P
3/8” x 2-3/4” Bolt (2)
3/8” Lock Washer (7)
V
3/8” x 1-1/2” Bolt (1)
Hairpin Clip (2)
#10-14 x 3/4” Screw (8)
N
O
3/8” x 1-1/2” Clevis Pin (2)
3/8” x 8” Bolt (4)
8” Nylon Cable Tie (10)
Operator
Arm
Gate Bracket
Post Pivot Bracket
Post Brackets
Closed Position
Stop Plate
3/8” x 1-1/2” Bolt (1)
5/16” x 1-1/2” Bolt (1)
3/8” Washer (9)
5/16” Washer (1)
3/8” Nut (7) 5/16” Lock Nut (1)
Hairpin Clip (2)
2” Mounting Screw (4)
F
G
E
B
H
J K
N
L
Q
S
O
P
M
R
U
T
3/8” x 2-3/4” Bolt (2)
3/8” Lock Washer (7)
V
ITEMS INCLUDED FOR PRIMARY GATE OPENER INSTALLATION (MM571W)
ITEMS INCLUDED FOR SECONDARY OPENER INSTALLATION (MM572W)
