Mighty Mule MM571W - Push-To-Open Operator Mounting Steps

8 MM571W / MM572W Installation Instructions
PUSH-TO-OPEN OPERATOR MOUNTING
G
V
T
O
L
G
11”
S
S
E
F
B
N
N
G
V
T
O
L
G
11”
S
S
E
F
B
N
N
Step 1
Step 2
● Assemble the gate post bracket subassembly
as shown with the Push-to-Open pivot bracket
(FM148). Must be purchased separate.
● Attach the gate post bracket subassembly and
gate bracket to the operator as shown.
Your Property
Push-to-Open pivot
bracket (FM148)
