OM-281138 Page 11
3-2. Miscellaneous Symbols And Definitions
. Some symbols are found only on CE products.
Output
X
Duty Cycle
Input
Constant Current
Trigger Hold Off
I
1
Primary Current
Wire Type
Arc Control
Single Phase
Read Instructions
A
Amperes
V
Volts
Direct Current
(DC)
Hz
Hertz
Set Up
Increase
Process
Time
Postflow Time
Gas Input
Percent
Purge By Gas
Constant Voltage
I
2
Rated Welding
Current
Program
IP
Degree Of
Protection
Variable
Inductance
Preflow Time
Line Connection
U
2
Conventional
Load Voltage
Wire Feed
Cold Jog (Inch)
Towards
Workpiece
Circuit Breaker
Trigger Hold On
Sequence
Gas Type
Trigger Control
Three Phase
U
1
Primary Voltage
