SECTION 4 − SPECIFICATIONS
4-1. Serial Number And Rating Label Location
The serial number and rating information for this product is located on the rear panel. Use rating label to determine input power requirements and/or
rated output. For future reference, write serial number in space provided on back cover of this manual.
4-2. Unit Specifications
Type of Input
Power
Welding Power
Source Type
Wire Feed
Speed Range
Wire
Diameter
Range
Welding
Circuit Rating
Overall
Dimensions
Weight
24 Volts AC Single
Phase
3.5 Amperes
50/60 Hz
Constant Voltage
(CV) DC With
14-Pin And
Contactor Control
75 to 750 ipm
(1.9 To 19 mpm)
.023 To 5/64 in.
(0.6 To 2 mm)
Max Spool
Capacity:
18 in. (457 mm)
Max Spool Weight:
60 lb (27 kg)
100 Volts,
500 Amperes,
100%
Duty Cycle
Length: 27-7/8 in.
(708 mm)
Width: 12-3/8 in.
(314 mm)
Height: 16 in.
(406 mm)
46 lb (20.8 kg)
4-3. Wire Type, Size and Feed Speed Table
Motor Speed Wire Type Wire Size Rated Speed Range*
Standard All
.023 To 5/64 in.
(.6 to 2 mm)
80 to 740 ipm
(2.0 to 18.8 mpm)
*Rated Speed Range Per IEC 60974-5
4-4. Environmental Specifications
A. IP Rating
IP Rating
IP21S
This equipment is designed for indoor use and is not intended to be used or stored outside.
IP21S 2014−06
B. Temperature Specifications
Operating Temperature Range Storage Temperature Range
14 to 104°F (−10 to 40°C) −4 to 131°F (−20 to 55°C)
Temp_2016- 07
C. Information On Electromagnetic Compatibility (EMC)
! This Class A equipment is not intended for use in residential locations where the electrical power is provided by the public low−
voltage supply system. There can be potential difficulties in ensuring electromagnetic compatibility in those locations, due to con-
ducted as well as radiated disturbances.
ce-emc 3 2014-07
