Miller DYNASTY 700 User Manual

OM-216 869 Page 69
7-2. Blowing Out Inside of Unit
803 900-B
! Do not remove case when
blowing out inside of unit.
To blow out unit, direct airflow
through front and back louvers as
shown.
m30 Torx
Tools Needed:
7-3. Coolant Maintenance And Oiling Motor
804 649-A / Ref. 801 194
! Disconnect input power be-
fore maintaining.
1 Coolant Filter
Unscrew housing to clean filter.
Changing coolant: Drain coolant by
tipping unit to rear, or use suction
pump. Fill with clean water and run
for 10 minutes. Drain and refill with
coolant (see section 4-19).
 If replacing hoses, use hoses
compatible with ethylene gly-
col, such as Buna-n, Neo-
prene, or Hypalon. NOTE:
Oxy-acetylene hoses are not
compatible with any product
containing ethylene glycol.
1

Miller DYNASTY 700 Specifications

General

Output Range	5 - 700 A
Output Voltage Range	10 - 40 V
Max Open Circuit Voltage	80 V
Processes	TIG, Stick
Duty Cycle	60% at 700 A
Rated Output	700 A at 60% Duty Cycle
