3-2. Miscellaneous Symbol Definitions
 Some symbols are found only on CE products.
A
Amperage
V
Voltage
Hz
Hertz
Temperature
Direct Current
(DC)
Alternating
Current (AC)
Panel/Local
Line Connection
Three Phase
Output
Input
On
Off
Submerged Arc
Welding (SAW)
Read Operator’s
Manual
Fuse
Single Phase
X
Duty Cycle
Percent
U
0
Rated No−Load
Voltage (OCV)
U
1
Primary Voltage
U
2
Conventional
Load Voltage
I
1
Primary Current
I
2
Rated Welding
Current
I
1max
Rated Maximum
Supply Current
I
1eff
Maximum
Effective Supply
Current
IP
Degree Of
Protection
Protective Earth
(Ground)
Circuit Breaker
Supplementary
Protector
Negative Weld
Output Terminal
Positive Weld
Output Terminal
Increase/
Decrease
3-Phase Power
Source With
AC/DC Output
Ventilating And Air
Circulating Fan
Work Connection
Electrode
Connection
Caution
Frame Or Chassis
TE Terminal Strip
Wire Feed Speed
Postflow Timer
Preflux Timer
Start Time
Start
Stop
Wire Feed Inch
Down
Wire Feed Inch
Up
Crater Time
Program
Flux
Display Push
Button
Lock
Remote
