Maintenance
Elix® 20, 35, 70 and 100 44
INSTALLING THE NEW QGARD TL PACK
Remove the new QGard TL Pack from its shipping box. Verify the Millipore SAS Catalogue Number by looking at the sticker
on the side of the QGard TL Pack. Remove the plastic covers on the 2 ports of the QGard TL Pack. Look inside the ports to
locate the black rubber O-rings. Make sure these are pushed in so they are firmly in-place. Wet the QGard TL Pack O-rings
with water.
Look below the ports on the top of the QGard TL Pack. Locate the TAG Sensor.
After the used QGard TL Pack is removed, install the new QGard TL Pack with the TAG Sensor at the top. The Elix System will
automatically identify the QGard TL type by accessing data contained on the Pack TAG. Normally the Elix System will
recognise and accept the information from the QGard TL Pack.
Make sure the ports of the new Pack are pushed in. After this, secure the Pack in place by pushing down on the Pack
Locking Handle.
Press CONTINUE to go back to PRODUCTION Mode.
The QGard TL Pack has a Sensor (“TAG”) on it. The QGard TL Pack has to be
installed so that the Sensor is oriented at the top of the QGard.
Q
G
A
R
D
T L
A
D
E
B
Y
M
I L L I P
O
R
E
C
O
N
T
I N
U
E
P L
E
A
S
E
I N
S E
R
T
N
E W
Q
G
A
R
D
. T L
. . .
P O
L
I S
H
E R
P A
C
K
C
A
N
C
E
L
