Appendixes
Elix® 20, 35, 70 and 100 59
Chapter 7 APPENDIXES
APPENDIX 1 HOW TO CHANGE THE MAIN POWER FUSE
Follow the steps below to replace the main Power Fuse.
Place the Elix into STANDBY mode.
1. Turn off the Power Switch. It is located on the back of the cabinet just above the location where the Power Cord is plugged
into the Elix System.
2. Unplug the Power Cord from the Elix System.
3. Obtain the correct replacement fuse. There is a spare fuse located in the fuse holder. See Step 4.
It is very important to use the correctly sized replacement fuse. Failure to use the correct replacement fuse could result
in system damage or an electrical fire.
System Voltage Main Power Fuse Size
100 VAC ± 10%
10 Amp. T, 5 mm x 20 mm
Millipore SAS Spare Part Number FTPF04803
120 VAC ± 10%
10 Amp. T, 5 mm x 20 mm
Millipore SAS Spare Part Number FTPF04803
230 VAC ± 10%
10 Amp. T, 5 mm x 20 mm
Millipore SAS Spare Part Number FTPF04803
1. Use a small flathead screwdriver to open the Fuse Holder. This is located immediately above the point where the Power Cord
plugs in.
2. Remove the entire fuse holder. Replace the blown fuse (you can check the fuse for electrical continuity with an Ohmmeter).
3. Place the Fuse Holder back into the Elix System. Put the Power Cord back in. Turn on the Power Switch.
4. The LCD will show the type of system, the Elix System serial number and software version for a few seconds. Wait about
10 seconds for this to go away.
5. Place the Elix System into PRODUCTION Mode or whatever mode it was previously in.
CONTACT MILLIPORE SAS IF THE MAIN POWER FUSE BLOWS AGAIN.
