14
BeneVision N1
Quick Reference Guide
a. Select the technical alarm information area to enter the Alarms dialog.
b. Select the Technical Alarms tab.
c. Select the desired alarm.
d. Select the Main Menu
quick key or to return to the main display.
RESET ALARMS
To reset an alarm for the duration of the alarm on the N1 monitor, select the
Alarm Reset
quick key.
PAUSE ALARMS/PAUSE ALARM TONES
To pause alarms or alarm tones on the N1 monitor, select Alarm Pause quick
key to pause all the alarms, or select Audio Pause
quick key to pause audible
alarm tones.
WARNING: Selecting alarm pause or audio pause may affect current and future
alarms, including arrhythmias, depending on your department’s configuration.
SCREEN DISPLAY
To enter the screen selection dialog and adjust the main screen’s layout on the N1
monitor:
a. Select the Screen Setup
quick key.
Or
a. Select the Main Menu
quick key, and select Choose Screen from the
Display column.
b. Select the desired screen.
• Normal Screen: Real time waveforms and numeric parameters on the
main display (Configurable).
• Big Numerics: Up to 6 waveforms and numeric parameters in an
expandable view on the main display (Configurable).
• ECG Full Screen: (5, 6, or 12 lead wire set): 7 leads or 8 leads of ECG with
numeric parameters on the main display.
• ECG 12-Lead (Optional): 12 leads of ECG with numeric parameters on the
main display.
c. Select the Main Menu
quick key or to return to the main display.
To Next Page
