16
BeneVision N1
Quick Reference Guide
f. Select the Main Menu quick key or to return to the main display.
Note: The waveforms printed are determined by the Record Setup and Print
Setup dialogs on the N1 monitor.
Full Disclosure
The N1 monitors have the ability to store configured waveforms and associated
numeric information for up to 48 hours.
To adjust waveforms to be stored and print waveforms stored on a patient:
a. Select the Main Menu
quick key.
b. Select Full Disclosure tab from the Review column.
c. Select Setup.
d. Select the Storage tab and set the desired waveforms to be stored in the
monitor.
e. Select the Display(Maximum: 3) tab and set the desired waveforms to be
displayed on the Full Disclosure page.
f. Select
to return to the Full Disclosure page.
g. Select
to print to the independent printer.
h. Select the Main Menu
quick key or to return to the main display.
VOLUMES
The alarm volume, key volume, and QRS volume can be adjusted on the N1
monitor.
Alarm Volume
To adjust the alarm volume on the N1 monitor:
a. Select the Main Menu
quick key, and select Setup from the Alarm
column.
b. Select Alarm Volume.
c. Select volume ranging from X*-10 (0=Off 10=Max).
d. Select the Main Menu
quick key or to return to the main display.
*The minimum volume range(X) is configurable.
Key Volume
To Next Page
