15
BeneVision N1
Quick Reference Guide
Note1: The first waveform is always an ECG lead and HR is always located in the
first digital tile in the Normal Screen selection.
Note2: Digital and waveform display seelctions on the N1 monitor and Central
Monitoring System are independent.
REVIEW
Tabular Trends
To display Tabular trends on a patient:
a. Select the Main Menu
quick key.
b. Select Tabular Trends tab from the Review column.
c. Select Trend Group and specify trend category or select Custom for user
defined parameters to be displayed.
d. Select Interval to specify the time interval tabular trends are to be
displayed.
e. Select the Main Menu
quick key or to return to the main display.
To print Tabular trends on a patient on the N1 monitor to the printer:
a. Select the Main Menu
quick key.
b. Select Tabular Trends tab from the Review column.
c. Select
and confirm specified settings.
d. Select Print to the independent printer.
e. Select the Main Menu
quick key or to return to the main display.
Arrhythmia and Alarm Events
The Events page stores 1000 physiological and arrhythmia events on a patient
based on the Alarm Setup dialog.
To view and print an alarm event on a patient on the N1 monitor:
a. Select the Main Menu
quick key.
b. Select Events tab from the Review column.
c. Scroll and select event.
d. Select Detail to view the details of selected events.
e. Select
to print to the independent printer.
To Next Page
