BeneVision N22/BeneVision N19 Patient Monitor Service Manual 6-1
6 Disassembly and Repair
6.1 Tools
During disassembly and repair, the following tools may be required:
 Phillips screwdrivers
 Tweezers
 Needle nose pliers
 Cutting pliers
 Flat-bladed screwdriver
6.2 Preparations for Disassembly
Before disassembling the monitor, make following preparations:
 Stop monitoring the patient, turn off the monitor and disconnect all the accessories and peripheral devices.
 Disconnect the AC power supply then remove the battery. Before taking out the battery, remove the main unit
housing.
6.3 Whole Unit Disassembly
NOTE
 Before disassembly, make sure that the work surface is clean, smooth and free of debris that could cause
damage to the touchscreen.
 All disassembly and repairs should only be performed by qualified service personnel using anti static
precautions.
