7-6 BeneVision N22/BeneVision N19 Patient Monitor Service Manual
ITEM NO. Description Qty FRU part number
2 22 inch vertical LED board PCBA 1 051-001923-00
3 22 inch horizontal LED board PCBA 1 051-001922-00
4 22 inch LCD backlight cable 1 009-005112-00
5 22-inch LCD LVDS signal cable 1 009-005111-00
6
Speaker bracket 1
115-037489-00 Speaker 1
Speaker pad 1
7 D22 main bracket 1 042-013329-01
8 Alarm LED board interconnection line 1 009-005109-00
9 Display interface board PCBA (FRU) 1 115-044999-00
10 D22 rear housing 1 043-005871-02
11
Display rear housing cover assembly 1 043-006465-01
Cable management cover (silkscreen) 043-008962-00
12 Encoder assembly 1 115-050303-00
13 Handle assembly (without an encoder) 1 115-033716-00
14 22 inch handle cover kit 2 115-035456-00
15 Key seat 1 043-006119-00
16 Switch keypad board PCBA 1 051-001920-00
17 Switch key assembly 1 049-001031-00
18 USB interface board interconnection line 1 009-005106-00
19
Display interface board and keypad board
interconnection line
1
009-005104-00
20 Heater fix screw 4 041-008273-00
21
Display interface board and indicator & light sensor
board line
1
009-005124-00
22 USB interface board PCBA 2 051-001933-01
23
Small cross recessed pan head GB9074.5-88 M3X6
with pad
30
M04-004012---
