BeneVision N22/BeneVision N19 Patient Monitor Service Manual
7-
15
ITEM No. Name and Specification Qty Material Code
10 Terminal screw 2 /
11 Infrared lens 1 /
12 Standard spring washer GB/T93-1987 3 2 /
13 Barcode serial number label 1 (for module) 1 /
14 High-end Mindray patent label (English) 1 /
15 Pump shock pad 1 /
16
Air valve. Dual air valve (custom) 12VDC
normally-open line, 125 mm long
2 082-000864-00
17 Pump. 12VDC with 120 wire and connector 1 082-000862-00
18 Filter. Inline Filter43um 1/8”I.D.Tubing 2 /
19 630F flow restrictor 1 /
20 Silicone tube 11 /
21 Bracket (T8) 1 043-001964-02
22 Module waterproof pad (M51C) 1 /
23
M51C front panel maintenance package (Masimo
SpO2/IBP/analog FRU)
1
115-057209-00
M51C front panel maintenance package (Nellcor
SpO2/IBP/analog FRU)
115-044673-00
To Next Page
