12-6 Setup
Type Item Description
Steer
To set the steer mode in B+ Color +PW/CW imaging
mode.
C&(PW/CW): select to adjust the sample volume in
color mode and sample line in PW or CW mode
together.
C/(PW/CW): select to adjust the sample volume in
color mode and sample line in PW or CW mode
individually.
Auto Invert
The spectrum can automatically invert when the color
flow is steered to a certain angle, thus accommodating
operator’s habit of distinguishing flow direction.
Auto Invert Past Zero Set smart invert mode of Color Map.
B+Color Refresh with
PW/CW Sampling Line
Movement
To set whether to turn on the function that when
moving PW/CW sampling line, B+Color image is
activated under B+Color+PW/CW mode.
B+Color+PW UnFreeze
keeping PW
To set whether to retain PW images when unfreezn
under B+Color+PW mode.
iScape Ruler Display
To set if to display the iScape ruler on iScape imaging
mode.
12.1.4 Application
Open the page via [Setup] → [System] → [Application]. On this page, you can set the measurement
ruler and relevant information. For details, see the Operator’s Manual [Advanced Volume]
12.1.5 OB Preset
Open the page via “[Setup] → [System] → [OB].” On this page, you can set the gestational age
formula, fetal growth formula, fetal weight formula and relevant information. For details, see the
Operator’s Manual [Advanced Volume].
12.1.6 Key Configuration
Open the page via “[Setup] → [System] → [Key Config].”
