Mindray ePM 10M User Manual

13 - 9
The following figure shows the SpO
2
statistics area.
13.8.1 Selecting the Range of each SpO
2
Section and the Target Section
To define the SpO
2
range of each section, follow this procedure:
1. Select the SpO
2
statistics area.
2. From the To column select the SpO2 value at which corresponding section ends.
3. From the Target column select the target section. The target section is highlighted in green in the SpO
2
statistics area.
13.8.2 Selecting the SpO
2
Statistics Length
The Duration of SpO
2
statistics is configurable. From the SpO
2
statistics area, select the duration to redefine the
length of SpO
2
statistics.
13.9 SpO
2
Troubleshooting
This section lists the problems that might occur. If you encounter the problems when using the equipment or
accessories, check the table below before requesting for services. If the problem persists, contact your service
personnel.
NOTE
• For the physiological and technical alarm messages, see DAlarm Messages.
(1) Duration of SpO
2
statistics
(2)
Results of SpO
2
statistics
(3) Sections for statistics: The section in green indicates the target range.
(1)
(2)
(3)
Problem Solution
Do not see SpO
2
numeric area or waveform area
on the main screen
1. Check that the SpO
2
is set to display in the Screen Setup menu.
For more information, see
27.11The Other Settings.
2. Check that if the SpO
2
parameter switch is enabled. If not, enable
the SpO
2
measurement.For more information, see 3.11.1Switching
On or Off a Parameter
.
3. Check that the cable connections of SpO
2
sensor and the extension
cable are tight. Replace the SpO
2
sensor or the extension cable if
needed.
Dashes “- -” display in place of numerics. 1. Check that the cable connections of SpO
2
sensor and the
extension cable are tight. Replace the SpO
2
sensor or the extension
cable if needed.
2. Reconnect the SpO
2
sensor if the alarm SpO2 Sensor Off appears.
3. Check the PI value. If the PI value is too low, adjust the SpO
2
sensor,
or apply the sensor to the site with better perfusion.
4. Move the sensor to the place with weaker light, or cover the sensor
with shade cloth if the alarm
SpO2 Sensor Off appears.
Low amplitude SpO
2
signal 1. The SpO
2
sensor and NIBP cuff are placed on the same limb.
Change a monitoring site if necessary.
2. Check the PI value. If the PI value is too low. Adjust the SpO
2
sensor,
or apply the sensor to the site with better perfusion.
3. Check the sensor and its application site.
