21 - 9
21.2.10.2 Switching to Median Complex (for Glasgow Algorithm Only)
The median complex template displays 12-lead ECG waveforms on one page in 4 columns, with 3 lines in each
column, and one rhythm lead waveform at the bottom. Besides, a short vertical bar appears above each
waveform, marking the start and end position of P-wave and QRS-wave and the end position of T-wave.
To view Median Complex, follow this procedure:
1. Enter the 12-lead review page.
2. Select Median Complex.
Selecting Waveform can return to the 12-lead ECG waveform page.
21.2.10.3 Setting 12-Lead ECG Waveforms
To set the 12-lead ECG waveforms on the review page, follow this procedure:
1. Enter the 12-lead review page.
2. Set Speed, Gain, and Layout.
21.2.10.4 Printing the 12-Lead ECG Report
To print the 12-Lead ECG report, follow this procedure:
1. Enter the 12-lead review page.
2. Select .
21.2.11 ST Review Page
When ST analysis is enabled, the monitor saves ST segments and values at an interval of one minute. You can
review the latest 120 hours of ST data.
21.2.11.1 Entering the ST Review Page
Choose either of the following methods to enter the ST review page:
■Select the Review quick key → select the ST tab.
■Select the Main Menu quick key → from the Review column select ST.
21.2.11.2 Setting the ST Reference
You can set the currently displayed ST as reference. To do so, follow this procedure:
1. Enter the ST review page.
2. Select Set Reference.
• The ST baseline is used as ST reference by default.
21.2.11.3 Displaying/Hiding the ST Reference
To display or hide ST reference, follow this procedure:
1. Enter the ST review page.
2. Select Display Reference or Hide Reference.
21.2.11.4 Displaying/Hiding Markers
To display or hide markers, follow this procedure:
1. Enter the ST review page.
2. Select Display Marker or Hide Marker.
