Trio™ Operating Instructions 0070-10-0666-01 2 - 31
Operations Parameter Menus
2.4.2.3 Respiration Troubleshooting
MESSAGE/
PROBLEM REASON SOLUTION
RESP ALM LMT ERR Functional failure Notify hospital technician or
Customer Support
RR EXCEED Respiration value exceeds the
measurement range
Check patient, notify physician
Respiration
Waveform too
Large
Scales set inappropriately Change lead selection
Change Respiration scale
Respiration
Waveform too
Small
Patient breathing shallow or turned on
side
Change lead selection
Scale set inappropriately Change Respiration scale
ARTIFACT Respiration value equals the heart rate Check patient, notify physician
Shallow breathing Change Respiration scale, Adjust
leads
Cessation of breathing Check patient, notify physician
No Respiration
Waveform
Cable not connected Check cable connections
ESIS cable in use Use non-ESIS cable only for
Respiration detection
No Respiration rate
displayed
Cable not connected Check cable
ESIS cable in use Use non-ESIS cable only for
respiration detection
Cardiovascular Artifact Detected Check patient, notify physician
Change Respiration scale
Adjust leads
