Mini Speed Dome Camera - Privacy Zone Mask Setup; Mask Area Selection; Privacy Zone Size Adjustment

PRIVACY ZONE MASK Setup
HOW TO USE OSD MENU
PROVACY
ZONE
PRIVACY ZONE
MASK NO 1
D I S P L A Y
U N D E F I N E D
C L E A R M A S K
O F F
C A N C E L
< E D I T M A S K >
E X I T
BACK
E D I T M A S K 1
M O V E T O T A R G E T P O S I T I O N
[ N E A R : S E L E C T / F A R : C A N C E L ]
E D I T M A S K 1
[ N E A R : S A V E / F A R : C A N C E L ]
[ : A D J U S T M A S K W I D T H ]
[ : A D J U S T M A S K H E I G H T ]
Privacy Zone Area Setup
Select area in image to mask.
Mask No
Display
Clear Mask
Privacy Zone Size Adjustment
[1~4]
Select Mask number. If the selected mask has
already data，camera moves as it was set.
Otherwise，“UNDEFINED” will be displayed
under“Mask No”.
[ON/OFE]
Sets if camera makes mask shows or not on
images
[CANCEL/OK]
Deletes data in the selected mask NO .
Move camera to area to mask. Then the menu to adjust mask size will be
displayed.
Adjust mask size. Use joystick or arrow buttons to adjust mask size.
(Left/Right)
(Up/Down)
Adinsts mask width.
Adjusts mask height.
4
20
Spee d Dom e Camera Instruction Manual
