INSTALLATION
Roated Power
DC 12V
Input Voltage Range
DC 11V~18 V
Current Consumption
0.8A
Please,check the voltage and current capacity of rated power carefully.Rated power is indicated in the
back of main unit.
Power Connection
RS-485 Communication
For PTZ control,connect this line to keyboard and DVR. To control multiple cameras at the same time,
RS-485 communication lines of them is cibbected in parallel as shown balow.
2
9
Spee d Dom e Camera Instruction Manual
RS-4
8
5
(
-
)
R
S
-48
5
(+)
Power
Cabl i n g
BNC
Moinitor
Controller/DVR
Cabling Terminal Block
Keyboard Controller/DVR
RS-485
#1 #2 #n
